Bow Shackle Nut Bolt Type

Name: Bow Shackle Nut Bolt Type
Brand: K-Power
Availability: InStock

The Bow Shackle Nut Bolt Type is a robust and versatile connector used in lifting, hoisting, and rigging applications. Its wide bow design allows easy attachment of multiple slings, ropes, or chains, while the secure nut and bolt fastening ensures maximum safety under heavy loads. Manufactured from high‑strength alloy steel with a corrosion‑resistant finish, this shackle is built to withstand demanding industrial, construction, and marine environments.

Key Features:

Premium-quality shackles with a 4:1 safety factor
Forged carbon steel body for high load-bearing strength
Alloy steel pin for superior durability and wear resistance
Quenched and tempered heat treatment for enhanced toughness
Electro-galvanized finish for corrosion protection
Conforms to applicable international standards
Designed for higher fatigue resistance in repeated lifting cycles
Suitable for lifting, rigging, and load-securing applications

Ideal for professionals seeking safe and reliable lifting solutions, the Bow Shackle Nut Bolt Type delivers dependable performance across a wide range of rigging tasks.

Description

A heavy‑duty shackle with a wide bow and secure nut‑bolt fastening, designed for safe and versatile lifting, hoisting, and rigging operations.

K-Power Stainless Steel Bow Shackle

Size (mm)	Dimensions (mm)				WLL (kg)
Size (mm)	A	B	C	D	WLL (kg)
4	4	4	8	16	80
5	5	5	10	19	100
6	6	6	12	24	200
8	8	8	16	32	320
10	10	10	20	40	520
12	12	12	24	48	800
14	14	16	28	56	1100
16	16	20	32	64	1500
18	18	22	36	72	2100
20	20	25	40	76	3000
22	22	28	44	88	3500
25	25	32	50	100	5000
