Geared Trolley Heavy Model

The Geared Trolley Heavy Model is a robust, load‑handling device designed for smooth travel along I‑beam or monorail tracks. Built for heavy‑duty applications, it features a powerful motor drive and reinforced steel body that ensure safe and efficient movement of hoists and suspended loads. Precision wheels and advanced gearing provide stable operation under high capacities, while the compact design allows easy installation in industrial settings. Ideal for warehouses, construction sites, and manufacturing plants, this trolley delivers reliable performance in demanding environments.

Key Features:

  • Heavy‑duty motorized drive for effortless load travel
  • Reinforced steel construction for strength and durability
  • Precision wheels for smooth beam movement under heavy loads
  • Compact design for easy installation and operation
  • Suitable for industrial, construction, and warehouse applications

The Electric Trolley Heavy Model combines power, safety, and durability, making it a trusted solution for professionals handling large‑scale lifting and material transport.

A heavy‑duty motorized trolley built for smooth load travel along beams, ensuring safe and efficient material handling.

Capacity(t) I-beam width (mm) Min. turning radius(m) Weight(kg) A
mm
A
mm
A
mm
A
mm
0.5 68-126 0.9 10 280 121 190 108
1.0 80-146 1.0 13.5 280 239 214 120
2.0 80-168 1.1 19 310 270 248 145
3.0 88-168 1.3 29 356 319 323 200
5.0 100-170 1.4 40 400 346 357 210
10 122-203 1.7 90 400 475 400 230
20 122-203 5.0 215 475 798 575 300
